Thoughtflow

Thoughtflow lets you see inside your delegate’s thinking. After any conversation turn, you can open a visual map showing exactly how your delegate handled your request — no guesswork, no black box.

Thoughtflow viewer

What it shows

Each diagram traces one complete response from start to finish:

  • What you sent — the message your delegate received
  • Which AI model was called — and when
  • Which tools were used — for example, a web search or a calendar lookup
  • What those tools returned — the actual data the delegate worked with
  • How it reached its answer — including any time it escalated to a more powerful reasoning mode

Why it’s useful

When your delegate does something unexpected — or surprisingly good — Thoughtflow lets you understand exactly why. You can see which tool surfaced a piece of information, whether a search returned useful results, or why a response took the path it did.

How to use it

  1. Have a conversation with your delegate as normal.
  2. Open /thoughtflow/viewer in your browser.
  3. You’ll see a list of recent runs, newest first.
  4. Click any entry to open its diagram.

Each diagram is interactive — you can zoom and pan to explore the full flow.

Technical details

  • Artifacts are written to runtime-data/thoughtflow/ as .d2 source files plus rendered output.
  • Diagrams are generated in D2 format.

Viewer endpoints:

Path Purpose
/thoughtflow/viewer Index of all runs
/thoughtflow/viewer/:id View one run
/thoughtflow/raw/:id.d2 Raw D2 source
/thoughtflow/:id.:ext Rendered artifact (e.g. .svg, .png)

Reference example diagrams (included in the repo):

  • detail-run1-llm.d2 — a basic LLM call
  • detail-run2-weathercall.d2 — a tool call sequence
  • detail-run3-memwrite.d2 — a memory write

Debugging: set LEDGER_DEBUG=1 for extra structured logging from the event ledger that backs Thoughtflow.

See also: Operations → Logging.
